Energy Conservation & Emission Reduction
Ultra-Low Liquor Ratio Dyeing, achieves a liquor ratio range of 1:2 to 1:8, reduces water consumption by 50%, cuts steam usage by 50%, and saves labor costs by over 60%.
Low-Speed Spin Function
Adjustable speed up to 100 RPM. The floor is kept free of standing water, ensuring a clean and orderly workspace.
Intelligent Dyeing Program
Intelligent PLC touchscreen control for dyeing processes, enabling precise water, steam, and chemical dosing. Reduces manual intervention and batch-to-batch variations. Flexible editing of dyeing process timings and parameters for each step, with multi-formula memory storage. Automatic water volume calculation per step based on batch size and liquor ratio. Achieves standardized automated dyeing processes, mechatronic integration management, ensuring consistent product quality, reducing defect rates, and improving efficiency.
Unique Design
Compact and ingenious structural design featuring specially sized beaters to ensure thorough dye liquor penetration and uniform dyeing. Unique SS316L stainless steel muffler prevents localized thermal shock during chemical/temperature adjustments, avoiding uneven dyeing on sensitive fabrics. , prevents tangling/wrinkling. Features an illuminated glass viewing port for sample comparison.
High Degree of Automation
Curve-based chemical dosing control, proportional heating/cooling control, horizontal circulation system, indirect/direct heating options, filtration unit, and real-time PH monitoring module.
Automatic Chemical Feeding Tanks
Dual-tank dual-chemical feeding design with selectable modes for different dyes (optional multi-tank multi-chemical configurations).
High-Temperature 99℃
Machine interior temperature reaches 99℃ with enclosed insulation to minimize heat loss and enhance energy efficiency.
Flow-Based Water Inlet
Flow meter-controlled water inlet enables precise water volume settings for different processes.
Automatic Tilting Unloading:
Automatically unloads garments, reducing labor intensity and eliminating the need for manual unloading from the drum.
Broad Application Scope
Suitable for garment dyeing (reactive/pigment/sulfur dyeing) and softening finishing of cotton knit hoodies, woven casual pants, jeans, knit wool sweaters, socks, hats, and seamless underwear.
Premium Component Selection
International first-tier brand electrical components and bearings.
Central Control System Interface
Reserved interface for central control via office computer, enabling networked management.
